G10/FR4 Glass Reinforced Epoxy
Phenolic Copper Clad Sheet
Copper Clad Sheet- G10/FR4 Glass Reinforced Epoxy -
Order
Copper Clad G10-FR4 Sheet Online-Click Here
Technical Data
|
Copper Clad G10/FR4 Phenolic Sheet
Military Specifications and Underwriters Laboratories (UL) Ratings UL 94V0 MIL-I-24768
Operating Temp. 201º F to 300º F
Lead Times May Apply
|
| Thickness
Inches |
Width
Inches |
Length
Inches |
Oz
Copper |
#
Sides Cladded |
Stock
# |
Min
Order Qty |
Price |
Purchase
Online |
| .005" |
36 |
48 |
2 |
One
Side Copper |
KS-16051 |
6 |
$98.74 |
Buy Now
|
| .005" |
36 |
48 |
1 |
One
Side Copper |
KS-16027 |
7 |
$77.64 |
Buy Now
|
| .005" |
36 |
48 |
1/2 |
One
Side Copper |
KS-16110 |
7 |
$75.64 |
Buy Now
|
| .005" |
36 |
48 |
1/2 |
Two
Sided Copper |
KS-16099 |
6 |
$92.92 |
Buy Now
|
| .005" |
36 |
48 |
1 |
Two
Sided Copper |
KS-16066 |
6 |
$94.92 |
Buy Now
|
| .005" |
36 |
48 |
2 |
Two
Sided Copper |
KS-16064 |
4 |
$127.48 |
Buy Now
|
| .008" |
36 |
48 |
1 |
One
Side Copper |
KS-16110Q |
5 |
$81.12 |
* |
| .008" |
36 |
48 |
2 |
One
Side Copper |
KS-16110X |
5 |
$11024 |
* |
| .010" |
36 |
48 |
2 |
One
Side Copper |
KS-16052 |
5 |
$114.24 |
Buy Now
|
| .010" |
36 |
48 |
1 |
One
Side Copper |
KS-16028 |
6 |
$92.24 |
Buy Now
|
| .010" |
36 |
48 |
1/2 |
One
Side Copper |
KS-16111 |
6 |
$90.24 |
Buy Now
|
| .010" |
36 |
48 |
1 |
Two
Sided Copper |
KS-16014 |
5 |
$109.52 |
Buy Now
|
| .010" |
36 |
48 |
1/2 |
Two
Sided Copper |
KS-16013 |
5 |
$107.52 |
Buy Now
|
| .010" |
36 |
48 |
2 |
Two
Sided Copper |
KS-16065 |
4 |
$142.08 |
Buy Now
|
| .013" |
36 |
48 |
1 |
Two
Sided Copper |
KS-16008X |
7 |
$152.86 |
* |
| .015" |
36 |
48 |
2 |
One
Side Copper |
KS-16053 |
5 |
$117.10 |
Buy Now
|
| .015" |
36 |
48 |
1 |
One
Side Copper |
KS-16029 |
6 |
$96.92 |
Buy Now
|
| .015" |
36 |
48 |
1/2 |
One
Side Copper |
KS-16121 |
6 |
$92.92 |
Buy Now
|
| .015" |
36 |
48 |
1 |
Two
Sided Copper |
KS-16097 |
5 |
$112.20 |
Buy Now
|
| .015" |
36 |
48 |
1/2 |
Two
Sided Copper |
KS-16016 |
5 |
$110.20 |
Buy Now
|
| .015" |
36 |
48 |
2 |
Two
Sided Copper |
KS-16042 |
4 |
$144.78 |
Buy Now
|
| .020" |
36 |
48 |
2 |
One
Side Copper |
KS-16054 |
5 |
$128.52 |
Buy Now
|
| .020" |
36 |
48 |
1 |
One
Side Copper |
KS-16030 |
5 |
$107.68 |
Buy Now
|
| .020" |
36 |
48 |
1/2 |
One
Side Copper |
KS-16113 |
5 |
$103.68 |
Buy Now
|
| .020" |
36 |
48 |
1 |
Two
Sided Copper |
KS-16006 |
5 |
$122.96 |
Buy Now
|
| .020" |
36 |
48 |
1/2 |
Two
Sided Copper |
KS-16017 |
5 |
$120.96 |
Buy Now
|
| .020" |
36 |
48 |
2 |
Two
Sided Copper |
KS-16059 |
4 |
$155.52 |
Buy Now
|
| .025" |
36 |
48 |
2 |
One
Side Copper |
KS-16055 |
4 |
$145.24 |
Buy Now
|
| .025" |
36 |
48 |
1 |
One
Side Copper |
KS-16007 |
5 |
$110.88 |
Buy Now
|
| .025" |
36 |
48 |
1/2 |
One
Side Copper |
KS-16105 |
5 |
$106.88 |
Buy Now
|
| .025" |
36 |
48 |
1 |
Two
Sided Copper |
KS-15998 |
4 |
$126.16 |
Buy Now
|
| .025" |
36 |
48 |
1/2 |
Two
Sided Copper |
KS-16018 |
4 |
$124.16 |
Buy Now
|
| .025" |
36 |
48 |
2 |
Two
Sided Copper |
KS-16057 |
3 |
$171.26 |
Buy Now
|
| .031" |
24 |
36 |
1 |
One
Side Copper |
KS-5248K |
1 |
$63.25 |
Buy Now
|
| .031" |
24 |
36 |
1 |
Two
Side Copper |
KS-5246K |
1 |
$73.50 |
Buy Now
|
| .031" |
36 |
48 |
2 |
One
Side Copper |
KS-16056 |
4 |
$131.92 |
Buy Now
|
| .031" |
36 |
48 |
1 |
One
Side Copper |
KS-16024 |
5 |
$123.42 |
Buy Now
|
| .031" |
36 |
48 |
1/2 |
One
Side Copper |
KS-16115 |
5 |
$119.42 |
Buy Now
|
| .031" |
36 |
48 |
1 |
Two
Sided Copper |
KS-16008 |
4 |
$138.70 |
Buy Now
|
| .031" |
36 |
48 |
1/2 |
Two
Sided Copper |
KS-16019 |
4 |
$136.70 |
Buy Now
|
| .031" |
36 |
48 |
2 |
Two
Sided Copper |
KS-16034 |
4 |
$158.72 |
Buy Now
|
| .047" |
36 |
48 |
2 |
One
Side Copper |
KS-16067 |
4 |
$150.56 |
Buy Now
|
| .047" |
36 |
48 |
1 |
One
Side Copper |
KS-16022 |
4 |
$130.42 |
Buy Now
|
| .047" |
36 |
48 |
1/2 |
One
Side Copper |
KS-16116 |
5 |
$124.42 |
Buy Now
|
| .047" |
36 |
48 |
1 |
Two
Sided Copper |
KS-16009 |
4 |
$143.70 |
Buy Now
|
| .047" |
36 |
48 |
1/2 |
Two
Sided Copper |
KS-16020 |
4 |
$141.70 |
Buy Now
|
| .047" |
36 |
48 |
2 |
Two
Sided Copper |
KS-16035 |
4 |
$176.26 |
Buy Now
|
| .062" |
36 |
48 |
2 |
One
Side Copper |
KS-16058 |
3 |
$194.82 |
Buy Now
|
| .062" |
36 |
48 |
1 |
One
Side Copper |
KS-15999 |
3 |
$168.08 |
Buy Now
|
| .062" |
36 |
48 |
1/2 |
One
Side Copper |
KS-16117 |
4 |
$166.08 |
Buy Now
|
| .062" |
36 |
48 |
1 |
Two
Sided Copper |
KS-16010 |
3 |
$185.36 |
Buy Now
|
| .062" |
36 |
48 |
1/2 |
Two
Sided Copper |
KS-16021 |
3 |
$183.36 |
Buy Now
|
| .062" |
36 |
48 |
2 |
Two
Sided Copper |
KS-16036 |
3 |
$217.92 |
Buy Now
|
| .062" |
24 |
36 |
1 |
One
Side Copper |
KS-5249K |
1 |
$83.05 |
Buy Now
|
| .062" |
24 |
36 |
1 |
Two
Side Copper |
KS-5247K |
1 |
$95.10 |
Buy Now
|
| .080" |
36 |
48 |
1/2 |
Two
Side Copper |
KS-5247KP |
2 |
$181.92 |
Buy Now
|
| .093" |
36 |
48 |
2 |
One
Side Copper |
KS-16050 |
2 |
$274.72 |
Buy Now
|
| .093" |
36 |
48 |
1 |
One
Side Copper |
KS-16000 |
2 |
$245.28 |
Buy Now
|
| .093" |
36 |
48 |
1/2 |
One
Side Copper |
KS-16118 |
3 |
$241.28 |
Buy Now
|
| .093" |
36 |
48 |
1 |
Two
Sided Copper |
KS-16011 |
2 |
$260.56 |
Buy Now
|
| .093" |
36 |
48 |
1/2 |
Two
Sided Copper |
KS-16025 |
3 |
$258.56 |
Buy Now
|
| .093" |
36 |
48 |
2 |
Two
Sided Copper |
KS-16037 |
2 |
$293.12 |
Buy Now
|
| .125" |
36 |
48 |
2 |
One
Side Copper |
KS-16060 |
2 |
$342.72 |
Buy Now
|
| .125" |
36 |
48 |
1 |
One
Side Copper |
KS-16001 |
2 |
$311.28 |
Buy Now
|
| .125" |
36 |
48 |
1/2 |
One
Side Copper |
KS-16131 |
2 |
$305.28 |
Buy Now
|
| .125" |
36 |
48 |
1 |
Two
Sided Copper |
KS-16012 |
2 |
$325.36 |
Buy Now
|
| .125" |
36 |
48 |
1/2 |
Two
Sided Copper |
KS-16032 |
2 |
$322.56 |
Buy Now
|
| .125" |
36 |
48 |
2 |
Two
Sided Copper |
KS-16038 |
2 |
$357.12 |
Buy Now
|
| .156" |
36 |
48 |
2 |
One
Side Copper |
KS-16061 |
2 |
$454.92 |
Buy Now
|
| .156" |
36 |
48 |
1 |
One
Side Copper |
KS-16002 |
2 |
$416.88 |
Buy Now
|
| .156" |
36 |
48 |
1/2 |
One
Side Copper |
KS-16119 |
2 |
$410.88 |
Buy Now
|
| .156" |
36 |
48 |
1 |
Two
Sided Copper |
KS-16040 |
2 |
$430.16 |
Buy Now
|
| .156" |
36 |
48 |
1/2 |
Two
Sided Copper |
KS-16023 |
3 |
$428.16 |
Buy Now
|
| .156" |
36 |
48 |
2 |
Two
Sided Copper |
KS-16039 |
2 |
$462.72 |
Buy Now
|
| .187" |
36 |
48 |
2 |
One
Side Copper |
KS-16062 |
2 |
$537.74 |
Buy Now
|
| .187" |
36 |
48 |
1 |
One
Side Copper |
KS-16003 |
1 |
$492.84 |
Buy Now
|
| .187" |
36 |
48 |
1/2 |
One
Side Copper |
KS-16122 |
2 |
$488.84 |
Buy Now
|
| .187" |
36 |
48 |
1 |
Two
Sided Copper |
KS-16005 |
2 |
$508.12 |
Buy Now
|
| .187" |
36 |
48 |
1/2 |
Two
Sided Copper |
KS-16015 |
1 |
$506.12 |
Buy Now
|
| .187" |
36 |
48 |
2 |
Two
Sided Copper |
KS-16049 |
1 |
$540.68 |
Buy Now
|
| .250" |
36 |
48 |
2 |
One
Side Copper |
KS-16063 |
1 |
$696.32 |
Buy Now
|
| .250" |
36 |
48 |
1 |
One
Side Copper |
KS-16004 |
1 |
$644.08 |
Buy Now
|
| .250" |
36 |
48 |
1/2 |
One
Side Copper |
KS-16124 |
2 |
$638.08 |
Buy Now
|
| .250" |
36 |
48 |
1 |
Two
Sided Copper |
KS-16031 |
2 |
$657.36 |
Buy Now
|
| .250" |
36 |
48 |
1/2 |
Two
Sided Copper |
KS-16026 |
1 |
$655.36 |
Buy Now
|
| .250" |
36 |
48 |
2 |
Two
Sided Copper |
KS-16041 |
1 |
$689.92 |
Buy Now
|
Peel Strength:
1 Oz : 9 Lbs/in
2 Oz : 12 Lbs/in
Volume Resistivity Megaohn/CM C- 96/35/90 : 3.6 x 107
Water Absorbtion % D-24/23 : .06%
Dielectric KV D-48/50 : 43.0
Dielectric Strength 320 V/Mil at 1/8" Thickness
Dielectric Contstant D/24/23 : 4.37
Dissipation Factor : .014
Flexural Strength LW : 68,200 PSI
Flexural Strength CW : 64,400 PSI
Tensile Strength LW : 40,000 PSI
Tensile Strength CW : 35,000 PSI
Impact Strength 7.5 Ft Lbs/In Flatwise
Impact Strength 5.5 Ft Lbs/In Edgewise
Coefficiant of Linear Expansion : 10 x 10-6 In/In/oC
| |
|
