G7 Glass Reinforced Silicone

G7 Rods

G7 Glass Reinforced Silicone - natural (cream to white)

Technical Data Sheet    Chemical Resistance Chart
Composed of a continuous glass woven cloth base impregnated with a silicone resin binder, this grade has excellent heat and arc resistance. It has extremely good dielectric loss properties under dry conditions and good electrical properties under humid conditions, although the percentage of change is high.
Certifies to
NEMA G-7 MIL-I-24768/17 GSG, IEC 60893-3 Type 6 SI GC 201

NEMA grade G7 Glass-Cloth Reinforced Silicone -- natural color is typically cream to white. Composed of a continuous glass woven clothe base impregnated with a silicone resin binder, this grade has excellent heat and arc resistance. (Silicone thermosetting resins are among the best of all polymer materials in resistance to temperature. Hence, silicone is broadly used for high temperature electronic applications requiring low electrical losses. Silicone isn't as strong as epoxies and phenolics upon aging at lower temperatures but is stronger upon aging over 400� F.) G7 has extremely good dielectric loss properties under dry conditions and good electrical properties under humid conditions, although the percentage of change is high.

G7 Sheets    G7 Tubes

G7 Rods

4 Ft. Standard Lengths, lead times may apply on some diameters

Stock # Diameter Inches Price/Ft. Purchase Online
KR-1277

.125"

$6.28 Buy Now
KR-1278

.187"

$7.96 Buy Now
KR-1279

.250"

$8.30 Buy Now
KR-1280

.312"

$14.92 Buy Now
KR-1281

.375"

$17.38 Buy Now
KR-1282

.437"

$21.24 Buy Now
KR-1283

.500"

$26.70 Buy Now
KR-2909 .563" $32.94 Buy Now
KR-1284

.625"

$40.04 Buy Now
KR-1285

.750"

$50.26 Buy Now
KR-1285X .875 $63.80 Special Order
KR-1286

1.000"

$76.50 Buy Now
KR-1286W 1.125 $55.46 *
KR-1287

1.250"

$125.76 Buy Now
KR-1287X 1.375 $145.90 *
KR-1288

1.500"

$171.58 Buy Now
Tolerances

Under 1.375" Dia.

 + / - .001"

1.375" Dia. & Over

+ / - .003"
